DANA UNIVERSAL JOINT - 5-1310X
Cross References
1-0121, 1-0153, 1-0200, 10153, 10153BHD, 10153HD, 1310X, 41201, 5-153, 5-153X, 5-283X, 5-785X, 5002322, 51310X, 5153X, 5252X, 5283X, 5529X, 5625X, 5785X, 752.5153X, BL329, BL369, CP120X, CP121X, CP1310X, CP153X, CP200X, CR10153, DLCP120X, DLCP121X, DLCP153X, DS51310X, DS5153X, E51310X, FLT15153X, HD5153X, MS41201, N110121, NE10121, NE10153BF, NP10121, NP10153, NP10153BF, NP5121, S-2171, SP 5 153X, SP5-153X, SP51310X, SP5153X, SPI-5-1310X, SPI51310X, SPL22-1X, SPL22-6X, SPL221X, SPL226X, UJ369
Specifications
| Brand Label: | Spicer |
| Item-Level GTIN: | 00023913121181 |
| Hazardous Material Code (Y/N): | N |
| EXPI Data (Country of Origin): | US |
| EXPI Data (Harmonized Tariff Code (HTS)): | 8708998175 |
| Item Quantity Size UOM: | EA |
| Bearing Cap Diameter (1): | 1.062 IN |
| Bearing Cap Diameter (2): | 1.062 IN |
| Bearing Cap Diameter A (mm): | 26.975 MM |
| Bearing Cap Diameter B (mm): | 26.975 MM |
| Bearing Cap Type: | Round |
| Bearing Cap Type A: | OSR |
| Bearing Cap Type B: | OSR |
| California Proposition 65: | WARNING: Cancer - www.p65warnings.ca.gov |
| Grease Zerk Included: | Not Required |
| Greaseable: | No |
| Hardware Included: | No |
| Length A (In): | 3.219 IN |
| Length A (mm): | 81.8 MM |
| Length B (In): | 3.219 IN |
| Length B (mm): | 81.8 MM |
| Material: | Steel |
| Mounting Hardware Included: | No |
| OEM Mfg: | Spicer |
| OEM Series: | 1310/SPL22 |
| Pre Greased: | Yes |
| Prop 65: | Yes |
| Snap Ring Included: | Yes |
| Snap Ring Type: | External |
| SR(1)Brng Cap to Brng Cap(OSR): | 3.219 |
| SR(2)Brng Cap to Brng Cap(OSR): | 3.219 |
| Type: | OSR Style |
| Description (Long Product Description): | Universal Joint; Non-Greaseable |
| Description (Short Product Description): | U-Joint |
| Description (Extended Product Description): | Universal Joint; Non-Greaseable |
Features
- Backed by Dana design and engineering standards you trust to ensure your customers only come back satisfied.
- Built to meet OE standards set by Dana
- Genuine OE quality. Tested and proven.
- Tested and validated to rigorous OE specifications
