MGM C24 S-cam Brake - 1427001
Details
Early signs of failing spring brake chambers often go unnoticed without visual inspection. When performing routine maintenance on your semi-truck or other commercial vehicle, you may want to check to see if the brake chamber rod is bent; isn't fully retracting or chamber and slack adjusters are out of adjustment. It could be time for a replacement. After all, brake chambers should be replaced every two-five years.
This C24L S-cam brake (drum) is designed for heavy-duty commercial vehicles. C models feature a formed steel pressure cap (epoxy-coated) and formed steel non-pressure chamber (epoxy-coated). It also features heavy-duty nylon diaphragms. Its top and side air ports measure 3/8-18 inches NPTF and it contains the added benefit of a center hole shield (except Type 12 and 16). This long stroke C model s-cam brake chamber contains a 2.5 inch stroke; a 5/8 11 inch mounting bolt thread and a 1.57 inch mounting bolt length. Service size is 24. Its "A" measurement is 4.42 inches; "B" measurement is 3.67 inches; "C" measurement is 7.46 inches; "D" measurement is 4.75 inches; "E" measurement is 5/8-11 inches; and "F" measurement is 5/8-11 inches. Inlets measure at 3/8-18 inches and x-min measures 8 inches.
MGM's limited warranty depends on product and application. Contact us to learn more!
Since 1956, MGM has been a top solution provider of quality spring brake actuator technology and electronic brake monitoring systems servicing trucks, buses, and other types of heavy-duty commercial vehicles. When in need of replacement air disc brake parts and components for your heavy-duty application, turn to MGM Brakes!
Cross References
10810332, 1257110, 127240201, 127240211, 127240212, 127240213, 127240214, 127240230, 127240303, 1427001X, 1427230, 1427231, 150-240XL, 150-240XLTEC, 150240XL, 150240XLTEC, 162739, 162739-1, 162739-10, 162739-11, 162739-12, 162739-13, 162739-14, 162739-15, 162739-2, 162739-3, 162739-4, 162739-5, 162739-6, 162739-7, 162739-8, 162739-9, 162739-P3, 162739-P4, 1627391, 16273910, 16273911, 16273912, 16273913, 16273914, 16273915, 1627392, 1627393, 1627394, 1627395, 1627396, 1627397, 1627398, 1627399, 162739P3, 162739P4, 162786, 163018C1, 163050, 163091, 163091-2, 1630912, 163543, 163543-L, 163543-R, 163543L, 163543R, 163678, 163916, 164020, 164302, 164462, 164463, 164494, 164495, 164496, 164497, 164851, 164854, 165118, 165184, 165184-1, 165184-2, 165184-3, 165184-5, 1651841, 1651842, 1651843, 1651845, 165241, 165331, 165332, 165333, 165334, 165335, 165336, 165337, 165338, 165339, 165340, 165341, 165431, 165432, 165433, 165740, 165929, 165945, 166032, 166326, 19QE3141P3, 19QE3141P4, 19QE486, 19QE486P10, 19QE486P3, 19QE486P4, 19QE486P7, 19QE486P8, 19QE486P9, 234100, 2400001, 2400003, 2400SC, 24424193, 24SCD, 24SCN2, 24SCN2-C, 24SCN2C, 24SLS, 2530002947633, 277277, 288808N, 30019, 3510874, 3948985, 5007120, 50866011, 52400001, 53324, 53325, 5396-SC24L, 5396SC24, 5396SC24L, 5554-1427001, 55541427001, 6814202918, 6814205318, 745-800825, 745800825, 767653299242, 800825, 800825BXW, 800897, 800903, 800909, 800915, 800919, 811358, 811359, 82-15710-000, 821278, 8215710000, 8432297, 85107276, A2400, ABPN42A24SCD, BAN800825, BEN800825, BO24, BW800825, BX800825, D:SC24, DSC24, E-24S, E-24S-L, E-24S-LS, E24SL, E24SLS, FLTS24S18, HALSC24L, HD24S, HD24S-LS, HDXSC24L, HS24S-LS, HS24SLS, KN36240, MA36242, MBISC24L, MBW234100, MG1427001, MGM1427001, MIDKN36240, MIDSC24L, PLBSC24, R870024, R870024BK, R870024BULK, SAP1024L, SC24, SC2400, SC2400-LS, SC2400LS, SC24L, SC24L-MD, SC24LMD, SC24LS, T-24SCLS-00, T24SCLS00, TEC150240XL, TWDBEN800825, TYPE 24, TYPE24, V42 142001, V993276X24, ZAC800825, ZAJ1427001, ZZ2456001, ZZSC24, ZZSC24L
Specifications
| Brand | mgm brakes |
| Supersedes | 3948985 |
| Model Number | C24L |
| MPN | 1427001 |
| Width | 9 in. |
| UOM Quantity (Per Unit of Measure) | 1 |
| Unit of Measure (case, ea, drum, etc.) | each |
| Height | 10 in. |
| Benefits | This C24L S-cam brake (drum) is designed for heavy-duty commercial vehicles. C models feature a formed steel pressure cap (epoxy-coated) and formed steel non-pressure chamber (epoxy-coated). It also features heavy-duty nylon diaphragms. Its top and side air ports measure 3/8-18 inches NPTF and it contains the added benefit of a center hole shield (except Type 12 and 16). This long stroke C model s-cam brake chamber contains a 2.5 inch stroke; a 5/8 11 inch mounting bolt thread and a 1.57 inch mounting bolt length. Service size is 24. Its "A" measurement is 4.42 inches; "B" measurement is 3.67 inches; "C" measurement is 7.46 inches; "D" measurement is 4.75 inches; "E" measurement is 5/8-11 inches; and "F" measurement is 5/8-11 inches. Inlets measure at 3/8-18 inches and x-min measures 8 inches. |
Features
- 2.5 inch stroke
- 5/8 11 inch mounting bolt thread
- 1.57 inch mounting bolt length
- Service size is 24
- "A" measurement is 4.42 inches
- "B" measurement is 3.67 inches
- "C" measurement is 7.46 inches
- "D" measurement is 4.75 inches
- "E" measurement is 5/8-11 inches
- "F" measurement is 5/8-11 inches
- Inlets measure at 3/8-18 inches
- X-min measures 8 inches
Includes
C24L S-cam brake (drum)
Warranty
MGM's limited warranty depends on product and application. Contact us to learn more!
