Meritor STUD/WHL 22MM - 09001989 - MUST BE ORDERED IN MULTIPLES OF 4

This serrated wheel stud is headed and has a right hand thread direction. Headed and round, it has a .87 inch body length and a diameter of .888 inches. It is serrated with a serration length of .38 inches and a serration diameter of .939 inches. It contains a grade of 10.9. The length from under the head measures at 3 23/32 inches. Thread diameter measures at 22 millimeters with 1.5 threads per millimeter. The thread is M22 x 1.5 with a thread measurement of 2.57 inches. Lastly, head diameter is 1.31 inches and the head thickness is .31 inches.

This product comes with a one-year warranty.

Meritor is a leading global supplier of aftermarket brake products for heavy-duty commercial vehicles. With years of experience, they offer customers reliable truck parts for different vehicle applications that are high performance; easy to install and efficient.

Features

• Body Diameter: 0.890 in.
• Body Length: 0.87 in.
• Grade: 10.9
• Head Diameter: 1.31 in.
• Head Style: Round
• Head Thickness: 0.31 in.
• Length from Under Head: 3 23/32 in.
• Metric Thread Size: M22 X 1.5-6g
• Notes: Grade 10.9 is the metric equivalent of Grade 8
• OEM: Euclid E-9837
• Serration: Serrated
• Serration Diameter: 0.939 in.
• Serration Length: 0.38 in.
• Thread: M22 x 1.5
• Thread Diameter: 22.0 mm
• Thread Length: 2.57 in.
• Threads per Inch: 1.5 per mm
• Type: Headed
• Wheel End Thread Direction: RH

Includes

One stud

Warranty

One year

Cross Reference

E-9837
