WABCO 4S/4M Front Axle Abs Tractor Package - 4725003220 - 472 500 322 0
Details
ABS is an important component of any heavy-duty truck's braking system. Not only does ABS keep wheels grounded, but it helps to prevent lock-up; skidding; and losing control of vehicles.
This 4S/4M front axle package povides an alternative to separate valve installation by combining a quick release valve with two ABS modulator valves. This valve package is compatible with C, D and E Version ECUs. It contains a DIN 72585-A1-3.1-Sn/K1 electrical connection with .56 bar response pressure and 11 bar max operating pressure. Furthermore, this 12 volt unit includes a IP66, IP69K protection class and a temperature range of -40°C to +80°C with 6-8 PSI. Port measurements are as follow: Ports 1 and 2: 1/2 inch - 14 Dry Seal NPTF. Port 3: Exhaust.
This product's warranty may depend on type and vocation. Please contact our customer service team for more details.
For over 150 years, WABCO continues to be a global supplier of commercial vehicle technologies to maintain safer uptime in a greener environment.
Cross References
2S4725003220, 4725001209, 4725003220, 725003220, RBS4725003220, S472-500-322-0, S4725003220, TDAS4725003220, WAB4725003220, S4725003220
Specifications
| Operating Temperature Range | -40°C to +80°C |
| Port Size | 11990 |
| Crack Pressure | 4433 |
| Brand | wabco |
| Supersedes | R955414 |
| Protection | IP66, IP69K |
| Voltage | 12V DC |
| MPN | 4725003220 |
| Width | 6.7 in. |
| UOM Quantity (Per Unit of Measure) | 1 |
| Unit of Measure (case, ea, drum, etc.) | each |
| Height | 6.95 in. |
| Benefits | This 4S/4M front axle package povides an alternative to separate valve installation by combining a quick release valve with two ABS modulator valves. This valve package is compatible with C, D and E Version ECUs. It contains a DIN 72585-A1-3.1-Sn/K1 electrical connection with .56 bar response pressure and 11 bar max operating pressure. Furthermore, this 12 volt unit includes a IP66, IP69K protection class and a temperature range of -40°C to +80°C with 6-8 PSI. Port measurements are as follow: Ports 1 and 2: 1/2 inch - 14 Dry Seal NPTF. Port 3: Exhaust. |
Features
- 4S/4M
- Compatible with C, D and E Version ECUs
- DIN 72585-A1-3.1-Sn/K1 electrical connection
- .56 bar response pressure
- 11 bar max operating pressure
- 12 volt
- IP66, IP69K protection class
- Temperature range of -40°C to +80°C
- 6-8 PSI
- Ports 1 and 2: 1/2 inch - 14 Dry Seal NPTF. Port 3: Exhaust
Includes
One Front Axle Package
Warranty
This product's warranty may depend on type and vocation. Please contact our customer service team for more details.
