Meritor Genuine AY/FRT HUB - 0516067004

Product Description

HYDRAULIC BRAKE - HUB ASSEMBLY

Warranty information may be based on the product and application. Please contact us for additional information.

For years now, Meritor has been at the forefront of the trucking industry, and the Meritor Genuine AY/FRT HUB - 0516067004 is the ideal way to make sure you have the replacement part you've been looking for.

Features

• ABS Pilot Diameter: 5.325 in.
• Axle Application: Steer
• Axle Series: FF/FG
• Base Part Number: 16067
• Brake Type: Quadraulic
• Disc Bolt Circle Diameter: 7.25 in.
• Disc Bolt Pattern: 10
• Disc Bolt Size: 9/16-12 UNC-2B
• Flange Outer Diameter: 13.50 in.
• Fully Dressed: No
• GAWR (lb): 13200
• Hub Cap Bolt Circle Diameter: 4.50 in.
• Hub Cap Bolt Thread: 5/16-18 UNC-2B
• Hub Cap Pattern: 06
• Hub Style: Conventional
• Hub Type: Hub only
• IBS to OBS: 3.385/3.365 in.
• IBS to Outer Surface: 4.455/4.435 in.
• Inner Bearing Surface (IBS) to Mounting Face: 5.49 in.
• Inner Cone: HM212049
• Inner Cup: HM212011
• Oil Seal: A1205B2265
• Outer Cone: 3782
• Outer Cup: 3720
• Rotor Pilot Diameter: 6.00/5.997 in.
• Tone Ring: Y
• Wheel Pilot Diameter: 8.653/8.646 in.
• Wheel Stud: 09-001988
• Wheel Stud Bolt Circle Diameter: 11.25 in.
• Wheel Stud Hole: .906/.904 in.
• Wheel Stud Pattern: 10

Warranty

1 Year

Cross Reference

205 16067 004
