BorgWarner ISX15 Air Fan Hub - 010024141
Details
Product Description
The most common sign of a failing fan clutch is when the vehicle begins to overheat and it decreases in power, acceleration and fuel economy. The solution is to replace your thermal management components in your commercial truck. Doing so will improve engine cooling while reducing emissions and fuel consumption. When in need of replacement fan clutches, turn to BorgWarner!
This air operated engine cooling fan hub is designed for Cummins ISX 15 engines. It is typically found on Kenworth and Peterbilt vehicles (2013-2015). It contains a back pulley diameter measurement of 7.24 inches and an overall length measurement of 12.09 inches. It offers a 12PK belt configuration and 6.66 belt groove location. This fan hub comes with a 6 inch bolt circle dimension and 5 inch fan pilot diameter as well as 1.05 inch fan blad stud length. Its stud thread size measures 5/16-18 inches, as well. Vertical mounting distance measures at 2.21 inches while the horizontal mounting distance measures at 6.36 inches. Center of Jb to top right mounting hole measures 2.21 inches.
This product comes with a one year warranty.
Innovation; sustainability; efficiency. These are all terms that BorgWarner chants with pride as they serve the heavy-duty vehicle market and aftermarket truck community with quality thermal management products; transmission technologies; vehicle electronics and beyond. When in need of thermal management parts, such as fan clutches, for your commercial vehicle, choose to shop from one of the most trusted brands in the business - BorgWarner!
Features
- Designed for Cummins ISX 15 engines
- Kenworth and Peterbilt vehicles (2013-2015)
- Back pulley diameter measurement of 7.24 inches
- Overall length measurement of 12.09 inches
- 12PK belt configuration
- 6.66 belt groove location
- 6 inch bolt circle dimension
- 5 inch fan pilot diameter
- 1.05 inch fan blad stud length
- Stud thread size measures 5/16-18 inches
- Vertical mounting distance measures at 2.21 inches
- Horizontal mounting distance measures at 6.36 inches
- Center of Jb to top right mounting hole measures 2.21 inches
Includes
Air operated engine cooling fan hub
Warranty
1 year
Cross Reference
1000-799782, 1000799782, 799782, 79A9782, 79A9782RMAN, 98A8200, 98A9782, 99782-2, 997822, 99A8200, 99A9782, F17-1031-001, F17-6009M22, F17-6014M22, F17-6017M03, F171031001, F176009M22, F176014M22, F176017M03, HOR79A9782, RC799782, RX79A9782RMAN
Specifications
Brand | BorgWarner Thermal Systems |
MPN | 010024141 |
UOM Quantity (Per Unit of Measure) | 1 |
Unit of Measure (case, ea, drum, etc.) | each |
Benefits | This air operated engine cooling fan hub is designed for Cummins ISX 15 engines. It is typically found on Kenworth and Peterbilt vehicles (2013-2015). It contains a back pulley diameter measurement of 7.24 inches and an overall length measurement of 12.09 inches. It offers a 12PK belt configuration and 6.66 belt groove location. This fan hub comes with a 6 inch bolt circle dimension and 5 inch fan pilot diameter as well as 1.05 inch fan blad stud length. Its stud thread size measures 5/16-18 inches, as well. Vertical mounting distance measures at 2.21 inches while the horizontal mounting distance measures at 6.36 inches. Center of Jb to top right mounting hole measures 2.21 inches. |
