MGM TR3036L3 Brake W/Welded Yoke - 3234951
Details
Product Description
Early signs of failing spring brake chambers often go unnoticed without visual inspection. When performing routine maintenance on your semi-truck or other commercial vehicle, you may want to check to see if the brake chamber rod is bent; isn't fully retracting or chamber and slack adjusters are out of adjustment. It could be time for a replacement. After all, brake chambers should be replaced every two-five years.
This TR3036L3 s-cam brake with welded mounting bolts is designed for parking brakes. The TR-L3 model with composite guide corrosion fighter technology features a tamper-resistant design and center hole diaphragm. It offers a long 3 inch stroke; weatherseal plug and weld reinforced non-pressure housing with welded bolts. This aftermarket unit with double diaphragm and welded yoke contains a service size of 30; a spring size of 36; port size measurement of 3/8-18 NPTF and a stroke of 3 inches. Its mounting bolt thread measures 5/8-11 and its mounting bolt length measures 1.49 inches. Its "A" measurement is 10.96 inches; "B" measurement is 8.62 inches; "C" measurement is 8.14 inches; "D" measurement is 9.18 inches; "E" measurement is 4.75 inches; F" measurement is 5/8-11 UNC and inlets are 3/8-18 NPTF. Y measures 2.25 inches.
MGM's limited warranty depends on product and application. Contact us to learn more!
Since 1956, MGM has been a top solution provider of quality spring brake actuator technology and electronic brake monitoring systems servicing trucks, buses, and other types of heavy-duty commercial vehicles. When in need of replacement air disc brake parts and components for your heavy-duty application, turn to MGM Brakes!
Features
- Welded yoke
- Service size of 30
- Spring size of 36
- Port size measurement of 3/8-18 NPTF
- Stroke of 3 inches
- Mounting bolt thread measures 5/8-11
- Mounting bolt length measures 1.49 inches
- "A" measurement is 10.96 inches
- "B" measurement is 8.62 inches
- "C" measurement is 8.14 inches
- "D" measurement is 9.18 inches
- "E" measurement is 4.75 inches
- F" measurement is 5/8-11 UNC
- Inlets are 3/8-18 NPTF
- Y measures 2.25 inches
Includes
TR3036L3 s-cam brake with welded mounting bolts
Warranty
MGM's limited warranty depends on product and application. Contact us to learn more!
Cross Reference
Mgm Brakes 3234951 Cross References
BTS3030LSWC, GC3036LCW, HALGC3036LCW, HDXGC3036LCW, NOCOMPXREF, PLBTS3030LSWC-6.80, PLBTS3030LSWC680, PLBTS3036LSWC-2.25, PLBTS3036LSWC225, S1373036002
Specifications
| Brand | mgm brakes |
| Model Number | TR3036L3 |
| MPN | 3234951 |
| Width | 1 in. |
| UOM Quantity (Per Unit of Measure) | 1 |
| Unit of Measure (case, ea, drum, etc.) | each |
| Height | 1 in. |
| Benefits | This TR3036L3 s-cam brake with welded mounting bolts is designed for parking brakes. The TR-L3 model with composite guide corrosion fighter technology features a tamper-resistant design and center hole diaphragm. It offers a long 3 inch stroke; weatherseal plug and weld reinforced non-pressure housing with welded bolts. This aftermarket unit with double diaphragm and welded yoke contains a service size of 30; a spring size of 36; port size measurement of 3/8-18 NPTF and a stroke of 3 inches. Its mounting bolt thread measures 5/8-11 and its mounting bolt length measures 1.49 inches. Its "A" measurement is 10.96 inches; "B" measurement is 8.62 inches; "C" measurement is 8.14 inches; "D" measurement is 9.18 inches; "E" measurement is 4.75 inches; F" measurement is 5/8-11 UNC and inlets are 3/8-18 NPTF. Y measures 2.25 inches. |
