MGM C24L3 Brake, Neo Diap, Welded Yoke -1428902
Details
Product Description
Early signs of failing spring brake chambers often go unnoticed without visual inspection. When performing routine maintenance on your semi-truck or other commercial vehicle, you may want to check to see if the brake chamber rod is bent; isn't fully retracting or chamber and slack adjusters are out of adjustment. It could be time for a replacement. After all, brake chambers should be replaced every two-five years.
This C24L3 s-cam brake with neoprene diaphragm, welded yoke is designed for service chambers. CL models feature a formed steel pressure cap (epoxy-coated) and formed steel non-pressure chamber (epoxy-coated). It also features heavy-duty nylon diaphragms. Its top and side air ports measure 3/8-18 inches NPTF and it contains the added benefit of a center hole shield (except C16 2.5). This long stroke aftermarket CL model s-cam brake chamber with welded yoke contains a 3 inch stroke; a 5/8-11 inch mounting bolt thread and a 1.55 mounting bolt length. Service size is 24. Its "A" measurement is 5.3 inches; "B" measurement is 4.22 inches; "C" measurement is 7.37 inches and "D" measurement is 4.75 inches. Its "E" measurement is 5/8-11 UNC. Inlets measure at 3/8 inches - 18 NPTF and Y measures at 2.25 inches.
MGM's limited warranty depends on product and application. Contact us to learn more!
Since 1956, MGM has been a top solution provider of quality spring brake actuator technology and electronic brake monitoring systems servicing trucks, buses, and other types of heavy-duty commercial vehicles. When in need of replacement air disc brake parts and components for your heavy-duty application, turn to MGM Brakes!
Features
- Welded yoke
- 3 inch stroke
- 5/8-11 inch mounting bolt thread
- 1.55 mounting bolt length
- Service size is 24
- "A" measurement is 5.3 inches
- "B" measurement is 4.22 inches
- "C" measurement is 7.37 inches
- "D" measurement is 4.75 inches
- "E" measurement is 5/8-11 UNC
- Inlets measure at 3/8 inches - 18 NPTF
- Y measures at 2.25 inches
Includes
C24L3 s-cam brake with neoprene diaphragm, welded yoke
Warranty
MGM's limited warranty depends on product and application. Contact us to learn more!
Cross Reference
127240030, 1428901, 1428901-MGM, 1428901MGM, 179.SC24XLW225, 179SC24XLW225, 24SCLW3, 3682379C91, 5396-SC24XLCW, 5396SC24XLCW, 5554-1428901, 5554-1428902, 55541428901, 55541428902, 767653331034, 85121097, BSC24LSWC, BXK058753, D413276X24, HDX S127240010, HDXS127240010, HDXSC24XLCW, K058753, K058753BXW, MGM1428901, MIDSC24XLCW, OTR24LSWC-2.25, OTR24LSWC225, PLBSC24LSWC-2.25, PLBSC24LSWC225, S127240010, SC24XLCW, ZAJ1428901, ZAJ1428902, ZZSC24XLCW
Specifications
| Brand | mgm brakes |
| Model Number | C24L3 |
| MPN | 1428902 |
| Width | 1 in. |
| UOM Quantity (Per Unit of Measure) | 1 |
| Unit of Measure (case, ea, drum, etc.) | each |
| Height | 1 in. |
| Benefits | This C24L3 s-cam brake with neoprene diaphragm, welded yoke is designed for service chambers. CL models feature a formed steel pressure cap (epoxy-coated) and formed steel non-pressure chamber (epoxy-coated). It also features heavy-duty nylon diaphragms. Its top and side air ports measure 3/8-18 inches NPTF and it contains the added benefit of a center hole shield (except C16 2.5). This long stroke aftermarket CL model s-cam brake chamber with welded yoke contains a 3 inch stroke; a 5/8-11 inch mounting bolt thread and a 1.55 mounting bolt length. Service size is 24. Its "A" measurement is 5.3 inches; "B" measurement is 4.22 inches; "C" measurement is 7.37 inches and "D" measurement is 4.75 inches. Its "E" measurement is 5/8-11 UNC. Inlets measure at 3/8 inches - 18 NPTF and Y measures at 2.25 inches. |
