MGM MJS3030ET Brake Chamber Combo - MJS3030ET082

*THIS PART IS NON-RETURNABLE*

Product Description

The MGM MJS3030ET Brake Chamber Combo - MJS3030ET082 was carefully developed to elevate the performance of your semi-truck's braking system. Designed with precision engineering, these Brake Chambers from MGM offer remarkable dependability and safety for your heavy-duty vehicles. Manufactured to withstand the most demanding conditions, MGM brake chambers deliver consistent and efficient braking power, granting peace of mind on the road. Rely on the MGM MJS3030ET Brake Chamber Combo - MJS3030ET082 to keep your fleet moving safely and efficiently.

Early signs of failing spring brake chambers often go unnoticed without visual inspection. When performing routine maintenance on your semi-truck or other commercial vehicle, you may want to check to see if the brake chamber rod is bent; isn't fully retracting or chamber and slack adjusters are out of adjustment. It could be time for a replacement. After all, brake chambers should be replaced every two-five years.

This MJS3030ET s-cam brake chamber with breather tube is designed for piston, parking brakes. This MJS 3 inch model features a tamper-resistant design and a 3 inch long stroke. Its compact size and new patented integral release bolt mechanism makes it desirable for commercial vehicles. It contains a minimum bolt protrusion (1.25 inches on long stroke models when manually released); a non-coil clash power spring; corrosion-resistant steel head - epoxy-coated and is available with 1749-2450 pounds of push rod braking force at 1.25 inch stroke/service brake sizes 17-36. This production unit features a 3 inch long stroke; port sizes of 3/8-18 inches; 5/8-11 mounting bolt thread and a 1.54 inch mounting bolt length. Service size is 30 and spring size is 30. It's "A" measurement is 10.73 inch; "B" measurement is 8.43 inches; "C" measurement is 8.32 inches; "D" measurement is 7.5 inches; "E" measurement is 4.75 inches; "F" measurement is 5/8-11 UNC; "G" measurement is 5/8-18 UNF and inlets are 3/8 - 18 NPTF.

MGM's limited warranty depends on product and application. Contact us to learn more!

Since 1956, MGM has been a top solution provider of quality spring brake actuator technology and electronic brake monitoring systems servicing trucks, buses, and other types of heavy-duty commercial vehicles. When in need of replacement air disc brake parts and components for your heavy-duty application, turn to MGM Brakes!

Features

• 3 inch long stroke
• Port sizes of 3/8-18 inches
• 5/8-11 mounting bolt thread
• 1.54 inch mounting bolt length
• Service and spring size is 30

Includes

One (1) S-cam brake chamber with breather tube

Warranty

MGM's limited warranty depends on product and application. Contact our customer service team for detailed warranty information.

Cross Reference

5554-MJS3030ET082, ZAJMJS3030ET082

Specifications
