Bendix New Ad9 Air Dryer Purge Valve Kit - 5004338

Details

As technology advances, so do the amount of applications that require the use of a truck's air system. Dealing with contaminated air can be detrimental for a vehicle's health, which makes Air Dryers and the systems attached to them vital for long term success. The last thing you want is down time due to brake system issues, so keep the air in your system clean with our Air Dryer Systems and their subsequent parts.


The Bendix Purge AD9 Air Dryer Purge Valve Kit 5004338 is designed for AD9 Air Dryer Systems. This from is designed to expel contaminants in the end cover sump during the purge cycle of the air dryer system. It allows air from the desiccant cartridge to reverse direction and flow to the open purge valve. It also removes oil and solid contaminants collected by the oil separator. This purge valve is a soft seat valve type. For a great way to make sure that you are using the right parts in your semi-truck, choose the Bendix AD9 Purge Valve Kit 5004338!


Bendix Commercial Vehicle Systems have been a staple in the heavy duty truck industry, providing cutting-edge safety technology, energy solutions and air brake solutions and systems for well over a century. They've pioneered systems that are now standard on heavy duty trucks. Bendix will always look out for your truck's future, which makes them the best option for your present. Trust Bendix with your truck's future, today.


Cross References

056436Z117, 107802, 107897, 109570, 109695, 109695X, 1215897, 1600867, 170.5004342, 34089, 5004338, 5004338N, 5004342, 5004342P, 5012782, 7455004338, 8210884002, 9515101898, A1211531AB, AV5004338, BE109570, BW109570, BW5004338, BW5004338N, BX109570, E-BN5004338N, G1012638, OTR109695, S-E278

Specifications

OE ManufacturerBendix
BrandBendix
Voltage24 Volts
MPN5004338
ColorBlack
VMRS013-010-083
UOM Quantity (Per Unit of Measure)1
Unit of Measure (case, ea, drum, etc.)each
BenefitsThis Purge Valve Housing Assembly is designed for AD9 Air Dryer Systems. The purge valve is designed to expel contaminants in the end cover sump during the purge cycle of the air dryer system. It allows air from the desiccant cartridge to reverse direction and flow to the open purge valve. It also removes oil and solid contaminants collected by the oil separator. This purge valve is a soft seat valve type.

Features

  • Expels contaminants in the end cover sump during the purge cycle
  • Allows air from the desiccant cartridge to reverse direction and flow to the open purge valve
  • Removes oil and solid contaminants collected by the oil separator
  • For AD9 Air Dryer Systems

Includes

One (1) Purge Valve Housing Assembly
