Meritor Premium ASA - M807023

Product Description

AIR BRAKE - ASA - HALDEX AA1 STYLE

Warranty depends on application and product type. Contact us for more information.

Meritor is a world leader of air brake, suspension, and drivetrain system parts for on-and-off highway vehicles. When in need of replacement truck parts, choose to buy from one of the best - Meritor!

Features

• Aftermarket Extended Warranty - Linehaul: 6 Years / 1 Million Miles
• Aftermarket Extended Warranty - Severe D: 2 Years / 100K Miles
• Angle: 34 degrees
• Application: Drive
• Arm Length: 5.00 in. or 6.00 in.
• Brake Size: 16.50 in.
• Bushing Inside Diameter: 0.625 in.
• Clevis Type: Unclevised
• Maximum Torque Rating: Less than 15 foot pounds
• Model: AA1 Replacement
• Notes: Premium version. Standard version is R806023A.
• OEM: Haldex
• Production Part Number: 409-10741
• Related Bracket Number: R810300
• Sensing Type: Clearance
• Slack Spline Count: 10
• Slack Spline Diameter: 1.50 in.
• Type: Unhanded

Includes

Premium ASA

Warranty

Warranty depends on application and product type. Contact us to learn more.

Specifications

Cross Reference

10-400-10142, 1040010142, 1640523, 195-184, 195184, 25QD260M2, 25QD410P2, 3508799, 3946523, 3946754, 3946757, 400-10142, 400-10159, 40010142, 40010142-MD, 40010142M1D, 40010142MD, 40010159, 409-10102, 409-10130, 409-10226, 409-10239, 409-10293, 409-10315, 409-10316, 409-10410, 409-10411, 409-10458, 409-10533, 409-10554, 409-10564, 409-10731, 409-10741, 40910102, 40910130, 40910226, 40910239, 40910293, 40910315, 40910316, 40910410, 40910411, 40910458, 40910533, 40910554, 40910564, 40910731, 40910741, 500-10142, 50010142, 506271, 509-10130, 509-10226, 509-10239, 509-10315, 509-10533, 509-10564, 509-10741, 50910130, 50910226, 50910239, 50910315, 50910533, 50910564, 50910741, 5396-40010142, 539640010142, 767653143385, 7883-40010142, 788340010142, 808124, 808140, 808161, 808177, 808687, 809615, 814505, 815789, 815808, 818222, 818990, 819031, ACA-0966A700, ACA0966A700, AS1031, AS1033, AS1131, AS1133, ASH40010142, BBH-RB-10142, BBHRB10142, BP10142, BXK041876, CS52342, CS56031, E-6923, E-6923A, E-6923B, E6923, E6923A, E6923B, GT-56142, GT56142, GTA-40010142, GTA40010142, HA-400-10142, HA40010142, HAE40010142, HAL40010142, HDX400-10142, HDX40010142, HX40010142, K041876, K041876BXW, MBI40010142, MID40010142, MK21103S, MK21103SG, MK41106S, MK41106SH, PL-10142, PL10142, PROSA56142, R806023, RB-10142, RB10142, S-23851, S23851, SA10102, SA1133A, WA10142, ZBRAS1133, ZSA40010142, ZZ40010142
