Meritor Premium ASA - M807002

Product Description

AIR BRAKE - ASA - HALDEX AA1 STYLE

Warranty depends on application and product type. Contact us for more information.

Meritor is a world leader of air brake, suspension, and drivetrain system parts for on-and-off highway vehicles. When in need of replacement truck parts, choose to buy from one of the best - Meritor!

Features

• Aftermarket Extended Warranty - Linehaul: 6 Years / 1 Million Miles
• Aftermarket Extended Warranty - Severe D: 2 Years / 100K Miles
• Angle: 0 degrees
• Application: Drive
• Arm Length: 5.50 in.
• Brake Size: 16.50 in.
• Bushing Inside Diameter: 0.625 in.
• Clevis Type: Unclevised
• Maximum Torque Rating: Less than 15 foot pounds
• Model: AA1 Replacement
• Notes: Premium version. Standard version is R806002A. Self-Setting alternative is M808004.
• OEM: Haldex
• Production Part Number: 409-10635
• Related Bracket Number: R810306
• Sensing Type: Clearance
• Slack Spline Count: 10
• Slack Spline Diameter: 1.50 in.
• Type: Unhanded

Includes

Premium ASA

Warranty

Warranty depends on application and product type. Contact us to learn more.

Specifications

Cross Reference

10-400-10155, 1004585, 1040010155, 400-10155, 40010155, 40010155M1D, 409-10085, 409-10101, 409-10223, 409-10294, 409-10370, 409-10417, 409-10565, 409-10635, 409-10662, 409-10787, 40910085, 40910101, 40910223, 40910294, 40910370, 40910417, 40910565, 40910635, 40910662, 40910787, 500-10155, 50010155, 506269, 509-10085, 509-10101, 509-10223, 509-10294, 509-10417, 509-10635, 50910085, 50910101, 50910223, 50910294, 50910417, 50910635, 5396-40010155, 539640010155, 767653143446, 7883-40010155, 788340010155, 808143, 808180, 808679, 808684, 809610, 810815, 813824, 817533, 823661, 973971, AS1032, AS1132, ASH40010155, BXK041870, E-10892, E10892, FLTAS1132, GUNAS-1132, GUNAS1132, HA-400-10155, HA40010155, HAL40010155, HDX40010155, HX400-10155, HX40010155, K041870, K041870BXW, MID40010155, PL-10155, PL10155, R806002, RB-10155, RB10155, SA1132A, ZBRAS1132, ZSA40010155, ZZ40010155
