  • Meritor Genuine AXLE SHAFT - 3202S9041

Meritor Genuine AXLE SHAFT - 3202S9041

Back

Details

The Meritor Genuine Axle Shaft - 3202S9041 offers a reliable and durable solution for heavy-duty transportation needs. Crafted with precision engineering, these from the specialists at deliver optimal performance under demanding conditions, providing longevity and stability on the road. Designed to meet industry standards, the Meritor Genuine Axle Shaft - 3202S9041 provides a trustworthy component for your semi-truck's drivetrain, promoting efficiency and minimizing maintenance requirements. Invest in the durability and resilience of the Meritor Genuine Axle Shaft - 3202S9041 to keep your fleet rolling smoothly.


DRIVE AXLE - AXLE SHAFT


Warranty depends on application and product type. Contact us for more information.


Meritor is a world leader of air brake, suspension, and drivetrain system parts for on-and-off highway vehicles. When in need of replacement truck parts, choose to buy from one of the best - Meritor!


Back

Cross References

1 3202S9041, 15617636, 1686031C1, 3202-M-9321, 3202M9321, 3202P9038, 3202S9041, 3202S9041-RI, 3202S9041RI, 3206-B-1016, 3206B1016, 6798632, 8235-3202S9041, 82353202S9041, AS1178, ATI3202S9041, E7HZ4234-H, E7HZ4234H, S-20536, S20536, TDA3202S9041

Back

Specifications

BrandMeritor Genuine
Number Of Splines / Teeth41
MPN3202S9041
UPC737238087519
Width8.5 in.
VMRS022-002-001
UOM Quantity (Per Unit of Measure)1
Unit of Measure (case, ea, drum, etc.)each
Height6 in.
Benefits

AXLE SHAFT


Features

  • Aftermarket Extended Warranty - General: 3 Years / 300K Miles
  • Body Diameter: 2.00 in.
  • Bolt Circle Diameter: 7.00 in.
  • Flange Diameter: 8.38 in.
  • Hole Count: 8
  • Hole Size: 0.73 in.
  • Hole Type: Taper
  • Length: 38.04 in.
  • Lube Holes: No
  • Puller Holes: No
  • Spline Count: 41
  • Spline Length: 2.88 in.
  • Spline Size: 2.10 in.

Includes

AXLE SHAFT


Warranty

Warranty depends on application and product type. Contact us to learn more.


Back

Returns, Warranty & Cores

For warranty, return, or core information please reach out to customer service or visit our Policy & Procedures page located at the footer of our website.
Back

Prop 65

WARNING: Cancer and Reproductive Harm -
