Meritor Genuine AXLE SHAFT - 3202Q8805
Details
Product Description
DRIVE AXLE - AXLE SHAFT
Warranty information may be based on the product and application. Please contact us for additional information.
For years now, Meritor has been at the forefront of the trucking industry, and the Meritor Genuine AXLE SHAFT - 3202Q8805 is the ideal way to make sure you have the replacement part you've been looking for.
Features
- Aftermarket Extended Warranty - General: 3 Years / 300K Miles
- Body Diameter: 2.25 in.
- Bolt Circle Diameter: 7.00 in.
- Flange Diameter: 8.38 in.
- Hole Count: 8
- Hole Size: 0.73 in.
- Hole Type: Taper
- Length: 37.44 in.
- Lube Holes: No
- Puller Holes: No
- Spline Count: 46
- Spline Length: 3.03 in.
- Spline Size: 2.35 in.
Includes
Meritor Genuine AXLE SHAFT - 3202Q8805
Warranty
Warranty information may be based on the product and application. Please contact us for additional information.
Cross Reference
1 3202Q8805, S-11916
Specifications
| Brand | Meritor Genuine |
| Number Of Splines / Teeth | 46 |
| MPN | 3202Q8805 |
| UPC | 737238087236 |
| Width | 8.5 in. |
| VMRS | 022-002-001 |
| UOM Quantity (Per Unit of Measure) | 1 |
| Unit of Measure (case, ea, drum, etc.) | each |
| Height | 6 in. |
| Benefits | AXLE SHAFT |
