Meritor Genuine AY-ASA-1.50-28 - R802512

Product Description

AIR BRAKE - ASA - MERITOR

Warranty depends on application and product type. Contact us for more information.

Meritor is a world leader of air brake, suspension, and drivetrain system parts for on-and-off highway vehicles. When in need of replacement truck parts, choose to buy from one of the best - Meritor!

Features

• Aftermarket Extended Warranty - General: 3 Years / Unlimited Miles
• Aftermarket Extended Warranty - Heavy Se: 3 Years / Unlimited Miles
• Aftermarket Extended Warranty - Linehaul: 5 Years / 500K Miles
• Aftermarket Extended Warranty - Off-High: 3 Years / Unlimited Miles
• Arm Length: 6.50 in.
• Brake Size: 20.25 in. x 7.00 in.
• Chamber Sizes: 36
• Clevis Thread Diameter: 0.625 in.
• Clevis Threads per inch: 18
• Clevis Type: Straight
• Maximum Torque Rating: More than 45 inch pounds
• Model: Meritor
• Notes: Green piston. Drum brake.
• OEM: Meritor
• Production Part Number: A8-3275-D-1148
• Related Clevis Kit: R810019
• Related Unclevised Number: R803058
• Sensing Type: Stroke
• Slack Spline Count: 28
• Slack Spline Diameter: 1.50 in.
• Type: Type 1

Includes

AY-ASA-1.50-28

Warranty

Warranty depends on application and product type. Contact us to learn more.

Cross Reference

00-20105, 00-20125, 03-05459, 05-563, 05563, 10-400-10211, 10-4NL-10211, 102117/18, 10211718, 10345905, 10345908, 10345911, 1040010211, 10480801, 104NL10211, 1142HDA, 1332831, 1352831, 1352840, 1362831, 20105, 20125, 20434458, 214617, 289314/15, 28931415, 2R802512, 305459, 3398-AS1042, 3398-AS1142, 3398AS1042, 3398AS1142, 3513974, 3523736, 3918361, 3946257, 3949413, 400-10011, 400-10101, 400-10106, 400-10146, 400-20211, 40010011, 40010011M1D, 40010101, 40010106, 40010146, 40010201, 40010211, 40010211-MD, 40010211M1D, 40010211MD, 40020211, 40020211M1D, 409-10091, 409-10094, 409-10126, 409-10197, 409-10215, 409-10222, 409-10228, 409-10229, 409-10236, 409-10237, 409-10240, 409-10312, 409-10386, 409-10398, 409-10399, 409-10408, 409-10416, 409-10430, 409-10444, 409-10471, 409-10506, 409-10530, 409-10532, 409-10551, 409-10553, 409-10580, 409-10679, 409-10682, 409-10683, 40910091, 40910094, 40910126, 40910197, 40910215, 40910222, 40910228, 40910229, 40910236, 40910237, 40910240, 40910312, 40910386, 40910398, 40910399, 40910408, 40910416, 40910430, 40910444, 40910471, 40910506, 40910530, 40910532, 40910551, 40910553, 40910580, 40910679, 40910682, 40910683, 429-10683, 42910683, 4NL10211, 500-10211, 50010211, 509-10236, 509-10237, 509-10398, 509-10471, 509-10683, 50910236, 50910237, 50910398, 50910471, 50910683, 516164, 5396-40010211, 539640010211, 556528, 6814201949, 76401-3510, 76401-3806, 764013510, 764013806, 767653143613, 7883-40010211, 788340010211, 805812, 808115, 808132, 808134, 808138, 808141, 808151, 808169, 808171, 808175, 808178, 808254, 808691, 808692, 810047, 810600, 810602, 810731, 810843, 811120, 811121, 812351, 813638, 813648, 815788, 815793, 815807, 815812, 818141, 8235-R802512, 8235R802512, 9628R802512, A1-3275A1119, A1-3275Z1118S, A12-3275C601S, A12-3275W595S, A123275C601S, A123275W595S, A13275A1119, A13275Z1118S, A15-3275C601S, A15-3275W595S, A153275C601S, A153275W595S, A2-3275A1119S, A2-3275C601S, A2-3275P718S, A2-3275W595S, A2-3275W59S, A23275A1119S, A23275A599, A23275A599S, A23275C601, A23275C601S, A23275P718S, A23275T592, A23275U593, A23275U593S, A23275W595, A23275W595S, A23275W59S, A2375W595, A34-3275M1079, A343275M1079, A35-3275M1079, A353275M1079, A4-3275P718S, A43275P718S, A463275Z1144S, A7-3275-D-1148S, A73275D1148S, ABPN42AS40010211, APA0994-2, APA09942, AS1004, AS1040, AS1042, AS1142, AS1149, ASH40010211, ATIR802512, BBH-RB-10211, BBHRB10211, BNDK043197, BP10211, BXK043197, CI22102, CI221A2, CS52320, CS52356, CS56001, CS56042, D00-20011, D0020011, E-091K, E-11403, E-11873, E-11902, E-168K, E-168K1, E-215K, E-229K, E-236K, E-237K, E-240K, E-6919, E-6919A, E-6920, E-6927, E-6927A, E-6927B, E-6944, E-6994, E-6994A, E091K, E11403, E11403A, E11873, E11902, E11921, E168K, E168K1, E215K, E229K, E236K, E237K, E240K, E6919, E6919A, E6920, E6927, E6927A, E6927B, E6944, E6994, E6994A, FLT40010211, GT-56211, GT56211, GTA-40010211, GTA40010211, GUAS1026, GUAS1042, GUAS1142, GUN AS1042, GUN AS1142, GUNAS1042, GUNAS1142, GUNAS1149, H2062, HA-400-10211, HA40010211, HAE40010211, HAL400-20211, HAL40010011, HAL40010211, HAL40020211, HDX400-10211, HDX40010211, HRR802512, HSA-5043, HSA5043, HX400-10211, HX40010211, K043197, K043197BXW, KN44061, KN52240, KN52241, KN52242, KN52243, KN52244, KSA10211, M807019, MB22102, MB22182, MB42101, MBI40010211, MID40010211, MK22102S, MK42101S, MSA40010211, N42AS, OTR10211, PL-10211, PL10211, PPAS1026, PROSA56211, R801076, R801081, R802444, R802445, R802500, R802501, R802502, R802503, R802504, R802505, R802510, R802511, R802512, R802513, R803058, R804000, R806019, R806026, RB-10211, RB10211, RBA23275W595S, RBR801076, RBR802512, S-23854, S213991, S23854, SA00203, SA00204, SA00503, SA00902, SA00904, SA01203, SA02204, SA02503, SA05503, SA05803, SA07004, SA07204, SA08104, SA08904, SA09204, SA10101, SA10204, SA10211, SA10804, SAP10211, SAS1004, SAS1026, SAS1042, SAS1142, SIRSA10211, TDAR802512, TWDR802512, WA10211, ZBRAS1040, ZBRAS1042, ZBRAS1142, ZBRAS1149, ZSA40010211, ZZ40010011, ZZ40010211, ZZ40020211
