Hendricson Tie Rod End, LH - 64002-001 - 064002-001
Details
Product Description
No matter the size job, we offer a full-haul catalog of replacement truck parts to get the work done with ease. Shop now!
12 LH thread pitch and direction tie rod. Rod outer diameter measures 1 1/4 inches. Center to end measures 7.37 inches. Height of taper measures 2.39 inches. Taper minor diameter measures .967 inches. Taper major diameter measures 1.107 inches. Taper length measures 1.08 inches. Stud thread is 7/8-14 inches.
This product features a warranty of 1 year.
Now that you've found the replacement truck part you are looking for, there is only one thing left to do: Add to cart now!
Features
- Ford trucks
Includes
Hendricson Tie Rod End, LH
Warranty
1 year
Cross Reference
Hendrickson 64002-001 Cross References
2R230146, 310-484, 310484, 3A131, 462.ES9001L, 4C4O-3A130-MA, 4C4O3A130MA, 4C4Z-3A130-MA, 4C4Z3A130MA, 60961-027, 60961-085, 60961027, 60961085, 64002001, 8235-R230146, 8235R230146, APL-101302, E-11789, E11789, ES3443L, F5HZ3A131AA, F6HZ3A131AA, HRR230146, L20SV5181B14, L20SV8151A13, L20SV8151B14, L20SV8151B16, L24SV8100D18, L2SV8100D12, QTE967L, R230146, S-F306, SF306, TDAR230146, TRE3443L
Specifications
| Brand | hendrickson |
| MPN | 64002-001 |
| UOM Quantity (Per Unit of Measure) | 1 |
| Unit of Measure (case, ea, drum, etc.) | each |
| Benefits | 12 LH thread pitch and direction tie rod. Rod outer diameter measures 1 1/4 inches. Center to end measures 7.37 inches. Height of taper measures 2.39 inches. Taper minor diameter measures .967 inches. Taper major diameter measures 1.107 inches. Taper length measures 1.08 inches. Stud thread is 7/8-14 inches. |
