MGM TR3030LP3THD Combo Brake -3233051
Details
Product Description
Early signs of failing spring brake chambers often go unnoticed without visual inspection. When performing routine maintenance on your semi-truck or other commercial vehicle, you may want to check to see if the brake chamber rod is bent; isn't fully retracting or chamber and slack adjusters are out of adjustment. It could be time for a replacement. After all, brake chambers should be replaced every two-five years.
This TR3030LP3THD s-cam brake with HD breather tube is designed for parking brakes. The TR-LP3THD model with composite guide-corrosion fighter technology features a tamper-resistant design and center hole diaphragm. It contains an epoxy-coated head and return spring (spring size is 30) as well as a center hole shield and weather-seal plug. With stroke alert, it has the added benefit of a 3 inch long stroke; molded nitrile rubber air seal and heavy-duty power spring at 145 pounds and additional parking brake force at 1.25 inches of stroke. This aftermarket long stroke double diaphragm s-cam brake drum with heavy-duty breather tube contains 3/8-18 inch NPTF port sizes; a spring size of 30 and a service size of 30. It's "A" measurement is 9.99 inches; "B" measurement is 7.61 inches; "C" measurement is 8.32 inches; "D" measurement is 8.21 inches; "E" measurement is 4.75 inches; "F" measurement is 5/8-11 UNC; "G" measurement is 5/8-18 UNF and inlets are 3/8 -18 NPTF. X-min measures 8 inches.
MGM's limited warranty depends on product and application. Contact us to learn more!
Since 1956, MGM has been a top solution provider of quality spring brake actuator technology and electronic brake monitoring systems servicing trucks, buses, and other types of heavy-duty commercial vehicles. When in need of replacement air disc brake parts and components for your heavy-duty application, turn to MGM Brakes!
Features
- Spring size is 30
- 3/8-18 inch NPTF port sizes
- Spring size of 30
- Service size of 30
- "A" measurement is 9.99 inches
- "B" measurement is 7.61 inches
- "C" measurement is 8.32 inches
- "D" measurement is 8.21 inches
- "E" measurement is 4.75 inches
- "F" measurement is 5/8-11 UNC
- "G" measurement is 5/8-18 UNF
- Inlets are 3/8 -18 NPTF
- X-min measures 8 inches
Includes
TR3030LP3THD s-cam brake with HD breather tube
Warranty
MGM's limited warranty depends on product and application. Contact us to learn more!
Cross Reference
5554-3233051
Specifications
| Brand | mgm brakes |
| Model Number | TR3030LP3THD |
| MPN | 3233051 |
| Width | 1 in. |
| UOM Quantity (Per Unit of Measure) | 1 |
| Unit of Measure (case, ea, drum, etc.) | each |
| Height | 1 in. |
| Benefits | This TR3030LP3THD s-cam brake with HD breather tube is designed for parking brakes. The TR-LP3THD model with composite guide-corrosion fighter technology features a tamper-resistant design and center hole diaphragm. It contains an epoxy-coated head and return spring (spring size is 30) as well as a center hole shield and weather-seal plug. With stroke alert, it has the added benefit of a 3 inch long stroke; molded nitrile rubber air seal and heavy-duty power spring at 145 pounds and additional parking brake force at 1.25 inches of stroke. This aftermarket long stroke double diaphragm s-cam brake drum with heavy-duty breather tube contains 3/8-18 inch NPTF port sizes; a spring size of 30 and a service size of 30. It's "A" measurement is 9.99 inches; "B" measurement is 7.61 inches; "C" measurement is 8.32 inches; "D" measurement is 8.21 inches; "E" measurement is 4.75 inches; "F" measurement is 5/8-11 UNC; "G" measurement is 5/8-18 UNF and inlets are 3/8 -18 NPTF. X-min measures 8 inches. |
