Meritor Genuine AY-ASA 1.50-28 - A63275M1183

Product Description

AIR BRAKE - ASA - MERITOR

Warranty depends on application and product type. Contact us for more information.

Meritor is a world leader of air brake, suspension, and drivetrain system parts for on-and-off highway vehicles. When in need of replacement truck parts, choose to buy from one of the best - Meritor!

Features

• Aftermarket Extended Warranty - General: 3 Years / Unlimited Miles
• Aftermarket Extended Warranty - Heavy Se: 3 Years / Unlimited Miles
• Aftermarket Extended Warranty - Linehaul: 5 Years / 500K Miles
• Aftermarket Extended Warranty - Off-High: 3 Years / Unlimited Miles
• Arm Length: 5.50 in.
• Bushing Inside Diameter: 0.50 in.
• Chamber Sizes: 16 or 20
• Clevis Type: Unclevised
• Maximum Torque Rating: More than 45 inch pounds
• Model: Meritor
• Notes: Red piston. Drum Brake.
• OEM: Meritor
• Sensing Type: Stroke
• Slack Spline Count: 28
• Slack Spline Diameter: 1.50 in.

Includes

AY-ASA 1.50-28

Warranty

Warranty depends on application and product type. Contact us to learn more.

Specifications

Cross Reference

05-563, 05563, 3275M1183, 3523728, 3947672, 8235-R803108, 8235R803108, A243275H1152, A733275H1152, ATIR803108, CS56040, CS56040M1D, MERR803108, R803108, R803108-RI, R803108RI, ROR803108, RWR803108, TDAA63275M1183, TDAR803108, TWDR803108, ZZCS56040
