Meritor Genuine AY-ASA-1.50-28 - R802487

Product Description

AIR BRAKE - ASA - MERITOR

Warranty depends on application and product type. Contact us for more information.

Meritor is a world leader of air brake, suspension, and drivetrain system parts for on-and-off highway vehicles. When in need of replacement truck parts, choose to buy from one of the best - Meritor!

Features

• Aftermarket Extended Warranty - General: 3 Years / Unlimited Miles
• Aftermarket Extended Warranty - Heavy Se: 3 Years / Unlimited Miles
• Aftermarket Extended Warranty - Linehaul: 5 Years / 500K Miles
• Aftermarket Extended Warranty - Off-High: 3 Years / Unlimited Miles
• Arm Length: 6.00 in.
• Chamber Sizes: 30
• Clevis Thread Diameter: 0.625 in.
• Clevis Threads per inch: 18
• Clevis Type: Straight
• Maximum Torque Rating: More than 45 inch pounds
• Model: Meritor
• Notes: Yellow piston. Drum brake.
• OEM: Meritor
• Production Part Number: A14-3275-C-1147
• Related Clevis Kit: R810019
• Related Unclevised Number: R803055
• Sensing Type: Stroke
• Slack Spline Count: 28
• Slack Spline Diameter: 1.50 in.
• Type: Type 2

Includes

AY-ASA-1.50-28

Warranty

Warranty depends on application and product type. Contact us to learn more.

Cross Reference

05-562, 055-040-04, 05562, 10600055, 106201, 106926, 107101, 107127, 107277, 107278, 107736, 107772, 107773, 107787, 107994, 108091, 108093, 108117, 108430, 1090263, 109519, 1141HDA, 1141TP, 1191037, 138.283, 1382830, 1392837, 25QD51P3, 289312, 289313, 289933, 289934, 3398-AS1141, 3398AS1141, 3512387, 3820002201, 40010140, 40010144, 40010212, 40020212, 40020234, 4017A23665, 42521, 4L-6-64, 4L664, 52529, 5504004, 56041, 600028, 65175, 65176, 76401-0100, 76401-3509, 764010100, 764013509, 8060858, 8084132, 809614, 815787, 815792, 8235-R802487, 8235R802487, 8235R803055, A-3275-X-596, A1-3275Z1092S, A10-3275N716S, A103275N716S, A11-3275N716S, A113275N716S, A13-3275-C-1147S, A13275Z1092S, A133275C1147S, A15-3275N716S, A153275N716S, A16-3275B600S, A16-3275N716S, A16-3275V594S, A163275B600S, A163275N716S, A163275V594S, A17-3275B600S, A17-3275V594S, A173275B600S, A173275V594S, A19-3275N716S, A193275N716S, A2-3275B600S, A2-3275L792S, A2-3275N716S, A2-3275V594S, A2-3275Y1091S, A2-3275Z1092S, A20-3275N716S, A203275N716S, A22-3275B600S, A22-3275V594S, A223275B600S, A223275V594S, A23275B600S, A23275L792S, A23275N716S, A23275V594S, A23275Y1091S, A23275Z1092S, A25-3275M1079, A253275M1079, A3275X596, A5-3275-N-716S, A51041, A53275N716S, ACCAS1141, ACF004205828, AS1041, AS1141, AS1173, ASM802487, ATIR802487, BNDK041877, BW065175, BW065176, BXK041877, CI22103, CI221A3, CI42106, CI421A6, CI72106, CS52321, CS52322, CS52345, CS52349, CS52355, CS52365, CS56004, CS56041, CS56041M1D, DLR801074, E-10781A, E-10788A, E-11402, E-11421, E-11422, E-11423, E-11424, E-6904, E-6918, E-6918A, E-6993, E-6993A, E10781A, E10788A, E11402, E11421, E11422, E11422A, E11423, E11424, E6904, E6918, E6918A, E6993, E6993A, E9HT2314AA, F8HT 2314 BA, F8HT2314BA, F8HZ2314BA, FLTAS1141, GNAS1041, GUA51041, GUAS1001, GUAS1041, GUAS1141, GUN AS1141, GUNAS-1141, GUNAS1141, GUNSA102 03, GUNSA10203, HDV-51141, HDV-65175, HDV175P, HDV65175, K020316, K041877, K041877BXW, KEAS1001, KEAS1041, KH600028, KHAS1001, KHAS1041, KHAS1141, KN44051, KN52210, KN52211, KN52212, KN52213, KN52214, M16WR1332, MB22103, MB22104, MB22183, MB22184, MB22953, MB42106, MB42186, MB72106, MDCS56004, MICS52321, MICS56004, MICS56041, MK22103S, MK22106S, MK42106S, MK72106S, MSAS1001, OTR-51141, OTR65175, P0065175, P0065176, P065175, P065176, PPAS1041, R21097004, R801069, R801071, R801074, R801075, R801086, R801087, R802480, R802481, R802482, R802483, R802486, R802487, R802487-RI, R802487RI, R802488, R802489, R802490, R802491, R802492, R802493, R803055, RBR801074, RBR802487, RDR801074, ROR801074, ROR802487, RSR801074, RWR802487, SA02201, SA02502, SA03602, SA04202, SA07003, SA07103, SA10203, SA10503, SA10803, SA11303, SA1141, SAS1055, SAS1057, SAS1058, SAS1062, SAS1141, SB889, SE889, TDAR802487, TDAR803055, TWDR802487, ZBRAS1141
