Accuride 22 In. Rear R-Spindle - 3946247

SKU 3946247
(0) No Reviews yet

Backordered

Details

Product Description

You may not be thinking about replacing your wheels as often as you should; but when you need replacement rims and other wheel end parts, you can always turn to Accuride, an industry leader with over 160 years working for all types of fleet vehicles.

This Accuride 6-spoke 22 inch diameter rear wheel R-spindle is designed for on-highway use. This R-spindle features a 594A inner bearing cone; 592A inner bearing cup; 580 outer bearing cone and a 572 outer bearing cup. Bearing cup spacing is 4.31. Its seal bore diameter is 6.3 with 7 drive/hub cap bolt circles and a (8).75-10 drive/hub cap hole pattern. Rotor mount offset is -.22. Its drum/rotor pilot diameter measures 11.25 in.. Lastly, it features a 6.81 in. spoke length and a 22 inch spoke wheel diameter measurement.

This product comes with a 5 year warranty.

Accuride comes with over 160 years of innovation to bring customers quality wheels and wheel end components for commercial vehicles. When in need of replacement wheel hub assembly parts, choose to ride with Accuride!


Features

  • 6-spoke
  • R-spindle
  • 594A inner bearing cone
  • 592A inner bearing cup
  • 580 outer bearing cone
  • 572 outer bearing cup
  • Bearing cup spacing is 4.31
  • Seal bore diameter is 6.3
  • 7 drive/hub cap bolt circles
  • (8).75-10 drive/hub cap hole pattern
  • Rotor mount offset is -.22
  • Drum/rotor pilot diameter measures 11.25 in
  • 6.81 in. spoke length
  • 22 inch spoke wheel diameter

Includes

6-spoke 22 inch diameter rear wheel R-spindle


Warranty

5 year


Cross Reference

RY231K


Specifications

BrandAccuride
MPNRY231K
Width1 in.
UOM Quantity (Per Unit of Measure)1
Unit of Measure (case, ea, drum, etc.)each
Height1 in.
Benefits

This Accuride 6-spoke 22 inch diameter rear wheel R-spindle is designed for on-highway use. This R-spindle features a 594A inner bearing cone; 592A inner bearing cup; 580 outer bearing cone and a 572 outer bearing cup. Bearing cup spacing is 4.31. Its seal bore diameter is 6.3 with 7 drive/hub cap bolt circles and a (8).75-10 drive/hub cap hole pattern. Rotor mount offset is -.22. Its drum/rotor pilot diameter measures 11.25 in.. Lastly, it features a 6.81 in. spoke length and a 22 inch spoke wheel diameter measurement.
