DANA Spicer End Yoke SPL170 Series 39 Spline - 17042411X - 17042411X

SKU 17042411X
$226.72
(0)No Reviews yet

Out of Stock

This item is currently on back order but can still be purchased

Back in stock on 07/04/2025.

Details

Product Description

When it comes to the best drivetrain components on the market, the Dana and Spicer brands are legendary. Prolong the life of your vehicle, experience reduced noise, vibration, and harshness during your journey, and enjoy performance mile after mile, no matter where your trip takes you. This SPL170 Series has 39 splines, an HR yoke style and 2.625 in. hub diameter.


Dana Spicer parts are typically warrantied for 1-3 years from the date of purchase depending on the part category and vocation.


Whether you are driving between the lines or outsideof them, you can expect the superior quality performance that comes from genuine Dana Spicer parts. When you buy genuine automotive aftermarket products including driveshaft components and axles, you will experience why Spicer is the undisputed leader among aftermarket driveshaft component manufacturers in the industry. From the invention of the encased universal joint that eliminated sprockets and chains to the production of fully integrated propulsion systems for today' most complex powertrains, the Dana and Spicer brands remain leaders in revolutionizing power conveyance.


Features

  • SPL170 Series
  • 39 splines
  • HR yoke style
  • 2.625 in. hub diameter

Includes

One (1) end yoke


Warranty

1-3 years depending on vocation and part category. See Dana Spicer warranty guide for more information.


Cross Reference


Dana 17042411X Cross References

170-4-241-1X, 17042411X, 170MU51P36, 170N-4-241-1X, 170N42411X, 176MU41P12, 8081933, DO17042411X, S-13866, S13866, SP17042411X


Specifications

Series2330
Brandspicer
Counter Bore Depth0.250 in.
Number Of Splines / Teeth39
MPN17042411X
Width9 in.
VMRS022004082
UOM Quantity (Per Unit of Measure)1
Unit of Measure (case, ea, drum, etc.)each
Type / StyleSplined Hole
Height8 in.
BenefitsThis SPL170 Series has 39 splines, an HR yoke style and 2.625 in. hub diameter.
