Meritor Genuine AY-HUB/STUD/ABS - 0515988001
Details
Product Description
HYDRAULIC BRAKE - HUB AND STUD ASSEMBLY
Warranty information may be based on the product and application. Please contact us for additional information.
For years now, Meritor has been at the forefront of the trucking industry, and the Meritor Genuine AY-HUB/STUD/ABS - 0515988001 is the ideal way to make sure you have the replacement part you've been looking for.
Features
- ABS Pilot Diameter: 6.546/6.543 in.
- ABS Ring Number: 09-002166
- Axle Application: Steer
- Axle Series: FL
- Base Part Number: 15988
- Brake Type: EX
- Disc Bolt Circle Diameter: 10.50 in.
- Disc Bolt Pattern: 10
- Disc Bolt Size: .659/.679 in.
- Flange Outer Diameter: 13.38 in.
- Fully Dressed: No
- GAWR (lb): 24000
- Hub Cap Bolt Circle Diameter: 5.50 in.
- Hub Cap Bolt Thread: 5/16-18 UNC-2B
- Hub Cap Pattern: 06
- Hub Style: Conventional
- Hub Type: Hub only
- IBS to OBS: 3.051/3.011 in.
- IBS to Outer Surface: 4.861/4.821 in.
- Inner Bearing Surface (IBS) to Mounting Face: 4.92 in.
- Inner Cone: 6461A
- Inner Cup: 6420
- Oil Seal: A1205M1339; A1205S2307
- Outer Cone: 555S
- Outer Cup: 552A
- Rotor Pilot Diameter: 8.497/8.493 in.
- Tone Ring: Y
- Wheel Pilot Diameter: 8.653/8.646 in.
- Wheel Stud: 09-001727
- Wheel Stud Bolt Circle Diameter: 11.25 in.
- Wheel Stud Hole: .904/.906 in.
- Wheel Stud Pattern: 10
Warranty
1 Year
Cross Reference
205 15988 001
Specifications
| ESC | 0 |
| Brand | Meritor Genuine |
| MPN | 515988001 |
| Width | 15 |
| VMRS | 018-002-001 |
| UOM Quantity (Per Unit of Measure) | 1 |
| Unit of Measure (case, ea, drum, etc.) | each |
| Height | 15.25 |
