Meritor Genuine COUPLING YOKE - 18N43591
Details
Product Description
END YOKE - 18N SERIES
Warranty information may be based on the product and application. Please contact us for additional information.
For years now, Meritor has been at the forefront of the trucking industry, and the Meritor Genuine COUPLING YOKE - 18N43591 is the ideal way to make sure you have the replacement part you've been looking for.
Features
- Bearing Cap Diameter: 1.94 in.
- Center To End: 5.50 in.
- Counter Bore Depth: 0.50 in.
- Hub Diameter: 2.88 in.
- Joint Angle: 32 degrees
- Series: 18N
- Spline Diameter: 2.390 in.
- Spline Length: 2.75 in.
- Use U-Joint Kit: M281X
- Yoke Dim. Across Ears: 7.55 in.
Includes
Meritor Genuine COUPLING YOKE - 18N43591
Warranty
Warranty information may be based on the product and application. Please contact us for additional information.
Cross Reference
Meritor 18N43591 Cross References
18N-4-3591, 18N4-3591, 18N43591, 18N43591-RI, 18N43591RI, 18NYS3826, 218N 4 3591, 6.5-4-3591, 6543591, 8235-18N43591, 823518N43591, ATI18N43591, N6.5-4-3591-1, N65435911, S-17720, S17720, TDA18N43591, TWD18N43591
Specifications
Series | 2292 |
Joint Angle | 8251 |
Depth | 0.50 in. |
Diameter | 1.94 in. |
Brand | Meritor Genuine |
Counter Bore Depth | 0.50 in. |
Center To End | 5.50 in. |
Number Of Splines / Teeth | 46 |
MPN | 18N43591 |
UPC | 737238889120 |
Width | 7.4 in. |
VMRS | 024-001-003 |
UOM Quantity (Per Unit of Measure) | 1 |
Unit of Measure (case, ea, drum, etc.) | each |
Height | 7.7 in. |
Benefits | COUPLING YOKE |
