MGM CS20L S-cam Brake - 1621098
Details
Product Description
Early signs of failing spring brake chambers often go unnoticed without visual inspection. When performing routine maintenance on your semi-truck or other commercial vehicle, you may want to check to see if the brake chamber rod is bent; isn't fully retracting or chamber and slack adjusters are out of adjustment. It could be time for a replacement. After all, brake chambers should be replaced every two-five years.
This CS20L S-cam brake (drum) is designed for heavy-duty commercial vehicles. CS models feature a formed steel pressure cap (epoxy-coated - CS20 models have zinc iron chomate coating) and formed steel non-pressure chamber (epoxy-coated). It also features heavy-duty nylon diaphragms. Its top and side air ports measure 3/8-18 inches NPTF and it contains the added benefit of a center hole shield. This sealed S-cam brake drum chamber with long stroke and welded yoke contains a 2.5 inch stroke and 5/8-11 inch mounting bolt thread. Service size is 20. Its "A" measurement is 4.37 inches; "B" measurement is 3.63 inches; "C" measurement is 7 inches and "D" measurement is 4.75 inches. Its "E" measurement is 5/8-11 UNC; "F" measurement is 5/8- 18 UNF. Inlets measure at 3/8 inches - 18 NPTF.
MGM's limited warranty depends on product and application. Contact us to learn more!
Since 1956, MGM has been a top solution provider of quality spring brake actuator technology and electronic brake monitoring systems servicing trucks, buses, and other types of heavy-duty commercial vehicles. When in need of replacement air disc brake parts and components for your heavy-duty application, turn to MGM Brakes!
Features
- Welded yoke
- 2.5 inch stroke
- 5/8-11 inch mounting bolt thread
- Service size is 20
- "A" measurement is 4.37 inches
- "B" measurement is 3.63 inches
- "C" measurement is 7 inches
- "D" measurement is 4.75 inches
- "E" measurement is 5/8-11 UNC
- "F" measurement is 5/8- 18 UNF
- Inlets measure at 3/8 inches - 18 NPTF
Includes
CS20L S-cam brake (drum)
Warranty
MGM's limited warranty depends on product and application. Contact us to learn more!
Cross Reference
1621098
Specifications
| Brand | mgm brakes |
| Model Number | CS20L |
| MPN | 1621098 |
| Width | 1 in. |
| UOM Quantity (Per Unit of Measure) | 1 |
| Unit of Measure (case, ea, drum, etc.) | each |
| Height | 1 in. |
| Benefits | This CS20L S-cam brake (drum) is designed for heavy-duty commercial vehicles. CS models feature a formed steel pressure cap (epoxy-coated - CS20 models have zinc iron chomate coating) and formed steel non-pressure chamber (epoxy-coated). It also features heavy-duty nylon diaphragms. Its top and side air ports measure 3/8-18 inches NPTF and it contains the added benefit of a center hole shield. This sealed S-cam brake drum chamber with long stroke and welded yoke contains a 2.5 inch stroke and 5/8-11 inch mounting bolt thread. Service size is 20. Its "A" measurement is 4.37 inches; "B" measurement is 3.63 inches; "C" measurement is 7 inches and "D" measurement is 4.75 inches. Its "E" measurement is 5/8-11 UNC; "F" measurement is 5/8- 18 UNF. Inlets measure at 3/8 inches - 18 NPTF. |
