Bendix R-12 Relay Valve - 102626N
Details
When it comes to truck maintenance, the Valve 2 102626 from provides the dependability needed for long hauls and tough conditions. This component features a height of 1.0 inches, a length of 1.0 inches, a width of 1.0 inches, making it a great fit for various repair and replacement needs. Weighing 3.31 lbs, it provides the strength and stability required for demanding operations. Whether for scheduled maintenance or an urgent repair, this aftermarket part helps keep trucks performing at their best.
Specifications
| Item-Level GTIN: | 4068078434963 |
| EXPI Data (Country of Origin): | Mx |
| Item Quantity Size UOM: | Ea |
| Description (Long Product Description): | Relay Valve |
| Balance / Primary Service Port: | Not Applicable To This Part |
| Body Configuration: | 1 Sup / 4 Del (V) |
| Cautionary Note(S): | Not Applicable To This Part |
| Control / Secondary Service Port: | 1/4-18 Npt |
| Control Port Orientation (Cw From Front Face): | Not Applicable To This Part |
| Crack Pressure: | 4.0 Psi |
| Delivery Port 1: | 1/2-14 Npt |
| Delivery Port 2: | 1/2-14 Npt |
| Delivery Port 3: | 1/2-14 Npt |
| Delivery Port 4: | 1/2-14 Npt |
| Delivery Port 5: | Not Applicable To This Part |
| Delivery Port 6: | Not Applicable To This Part |
| Delivery Port 7: | Not Applicable To This Part |
| Delivery Port 8: | Not Applicable To This Part |
| Exhaust Port: | Dust Shield |
| Internal Supply Passage To Cover: | Not Applicable To This Part |
| Market Indicator: | Aftermarket New |
| Maximum Operating Temperature: | 200 Adegf (93 Adegc) |
| Minimum Operating Temperature: | -40 Adegf (-40 Adegc) |
| Mounting: | .96 In X .40 In Slot (4X) |
| Mounting Bracket Direction: | Not Applicable To This Part |
| Mounting Bracket Location: | Loose In Box |
| Mounting Orientation (Cw From Front Face): | Not Applicable To This Part |
| Supply Port 1: | 1/2-14 Npt |
| Supply Port 2: | Not Applicable To This Part |
| Tmc Washer: | Rv040 |
