Bendix R-14 Relay Valve - 103028N
Details
The 103028N relay valve plays an essential role in heavy-duty truck air brake systems, delivering accurate air pressure management for responsive braking. Crafted for durability, it withstands the intense requirements of commercial operations. This product is available for purchase today to support your truck’s braking system.
Specifications
| Item-Level GTIN: | 7894294735372 |
| EXPI Data (Country of Origin): | Mx |
| Item Quantity Size UOM: | Ea |
| Description (Long Product Description): | Relay Valve |
| Balance / Primary Service Port: | 1/8-27 Npt (With Cover) |
| Body Configuration: | 1 Sup / 4 Del (V) |
| Cautionary Note(S): | Not Applicable To This Part |
| Control / Secondary Service Port: | 1/4-18 Npt |
| Control Port Orientation (Cw From Front Face): | 180Adeg |
| Crack Pressure: | 4.0 Psi |
| Delivery Port 1: | 1/2-14 Npt |
| Delivery Port 2: | 1/2-14 Npt |
| Delivery Port 3: | 1/2-14 Npt |
| Delivery Port 4: | 1/2-14 Npt |
| Delivery Port 5: | Not Applicable To This Part |
| Delivery Port 6: | Not Applicable To This Part |
| Delivery Port 7: | Not Applicable To This Part |
| Delivery Port 8: | Not Applicable To This Part |
| Exhaust Port: | Dust Shield |
| Internal Supply Passage To Cover: | Not Applicable To This Part |
| Market Indicator: | Aftermarket New |
| Maximum Operating Temperature: | 200 Adegf (93 Adegc) |
| Minimum Operating Temperature: | -40 Adegf (-40 Adegc) |
| Mounting: | .96 In X .40 In Slot (4X) |
| Mounting Bracket Direction: | Not Applicable To This Part |
| Mounting Bracket Location: | Loose In Box |
| Mounting Orientation (Cw From Front Face): | Not Applicable To This Part |
| Supply Port 1: | 1/2-14 Npt |
| Supply Port 2: | Not Applicable To This Part |
| Tmc Washer: | Rv040 |
